EXPANDED CONDUCTIVE SILICONE

GT 5000EX SP

GT5000 EX SP is an expanded conductive silicone elastomer filled
with silver-plated aluminum to provide conductive gasket especially
for aerospace applications. Working temperature : -55°C to +160°C

• Very low density
• Very stable in temperature
• Compatible with most alloys
• ESA-ECSS-Q-ST-70-02C compliance
• No oil

Thanks to a spatial qualification according to the ESA-ECSS-Q-ST-70-02C TML RML (<1%)
and CVCM (<0.1%) standard, the GT5000EX SP is suitable for aerospace applications.

Properties Standards- Test GT 5000EX SP Shielding efficacy
Elastomer Silicone
Conductive filler Silver plated aluminum
Working temperature -55°C to +160°C
(with adhesive) dB attenuation
Hardness Shore A 45 ± 5
Density (gm/cc) 1.0 ± 0.13
Vibration resistance MIL G 83528 Compliant
Volume resistivity Max 0.5 Ohm.cm Frequency
Shielding performance MIL G 83528 Compliant
TML ECSS-Q-ST-70-02C 0.18 % AVAILABLE FORMATS
RML ECSS-Q-ST-70-02C 0.15 %
CVCM ECSS-Q-ST-70-02C 0.08 %
Outgassing, with adhesive ECSS-Q-ST-70-02C Compliant Molded
Cut
Vulcanization bonding
Sheet
