CARBON FILLED FLUOROSILICONE
BL 10007
BL 10007 is a conductive carbon filled fluorosilicone elastomer
which enables the creation of sealed, conductive gaskets .
Can be allow in contact with solvents, hydrocarbons or hydraulic fluids.
• Good mechanical properties
• Good abrasion resistance
• Good resistance to salt spray
• UL157 compliance
• Low density
Properties Standards - Test BL 10007
Shielding efficacy
Elastomer binder Fluorosilicone
Conductive filler Carbon
Volume Resistivity Ω.cm MIL G 83528 2.7 dB attenuation
Hardness shore A ASTM D 2240 73
Density g/cm 3 ASTM D 792 Method A 1.23
Frequency
Break resistance Mpa ASTM D 412 Method A C 6.3
Elongation at break % ASTM D 412 Method A C 177.6
Tear resistance N/mm ASTM D 624 C 21.7
AVAILABLE FORMATS
Residual deformation after 70
hours of compression at 100°C ASTM D 395 Method B 18 Molded
Continuous usage -55°C to +125°C Cut
temperature
Extruded
Color Black
Sheet
Vulcanization bonding
