Page 43 - GETELEC - Products and solutions Catalog
P. 43
EXPANDED CONDUCTIVE SILICONE
GT 5000EX
GT 2020EX is an expanded conductive silicone elastomer filled GT 5000EX is an expanded conductive silicone elastomer filled
with pure silver to provide low-density seals and conductors. with silver-plated aluminum to provide low-density seals and
Working temperature : -55°C to +160°C . conductors. Working temperature : -55°C to +160°C.
• Very low density
• Very stable temperature
• Compatible with most alloys
Properties Standards - Test GT 5000EX
Elastomer binder Silicone
Conductive filler Silver-plated
aluminum
Hardness shore A (±5) ASTM D 792 48
Specific mass at 25°C (g/cm³) ASTM D 2240 0.96
MIL G 83528
Volume resistivity (Ω.cm) 0.025
on plate thickness 2mm
AVAILABLE FORMATS
Tensile strength (Mpa) ASTM D 412 Cut C 0.58
Molded
Elongation at break % ASTM D 412 Cut C 50
Cut
Vulcanization bonding
Tear strength (kN/m) ASTM D 624 Cut C 5.93
Sheet
Color Blue / Beige
www.getelec.com 43
