GTS RANGE GTR RANGE

THERMAL GAP PAD DEDICATED TO THE SLIMMEST THERMAL GAP PADS
SPACE INDUSTRY

• Low thickness
• High mechanical performance
• Nylon reinforcement
• Excellent thermal conductivity
• Low outgassing rate

Methods | Tests GTS 6-70R GTS 8-65 GTS -9-80 GTS 10-50 Methods | Tests GTG 3-35R GTG 3-70R GTG 5-40R

ASTM D 2240 Reinforcement used Nylon
Hardness ± 5 (Shore 00) 70 65 80 50
Measured after 3 seconds
ASTM D 2240
ASTM D 7984 Hardness ± 5 (Shore 00) Measured after 3 seconds 35 70 40
Thermal conductivity (w/m.K) Modified transient plane 6 ± 0.2 8.1 ± 0.1 9.1 ± 0.2 10.01 ± 0.2
source (MTPS)
Thermal conductivity (W/m.K) 3.1 ± 0.2 3.1 ± 0.1 5 ±0.2
Density (g/cm ) ASTM D 792 3.23 ± 0.01 3.3 ± 0.01 3.35 ±0.05 3.44 ±0.05
3
3
Elongation at break (%) ASTM D 412 > 100 > 20 > 20 > 20 Density (g/cm ) ASTM D 792 2.65 ±0.01 2.65 ±0.01 3.12 ±0.01

Dielectric strength (kV/mm) ASTM D 149 15 10 11 7 Break resistance (Mpa) ASTM D 412 > 1 0.6 > 1

Breakdown voltage (kV/mm) ASTM D 149 - 16 16 6
Elongation at break (%) ASTM D 5470 > 100 200 > 100
Volume resistivity (Ω.m) ASTM D 257 10 11 10 11 10 11 10 10
Dielectric constant @1Mhz ASTM D 150 - 7.9 8 3 Volume resistivity (Ω.m) 10 11 10 11 10 10
Dissipation factor @1Mhz ASTM D 150 - 0.013 0.010 0.006
Dielectric strength (kV.mm) 15
TML (%) ESA-ECSS-Q-ST-70-02C 0.09 0.07 0.07 0.08

RML (%) ESA-ECSS-Q-ST-70-02C 0.04 0.07 0.06 0.07 Working temperature (°C) -45°C to +200°C
CVCM (%) ESA-ECSS-Q-ST-70-2C 0.03 0.02 0.01 0.03
Working temperature (°C) -45°C to +200°C -40°C to +150°C -40°C to +160°C -40°C to +160°C Available thickness (mm) From 0.5 to 20 mm

Available thickness (mm) From 0.8 to 10 From 1.5 to 10 From 1 to 20 From 1 to 20 Color Light blue Light blue Turquoise

Flame retardant UL 94 - V0 V0 -
RoHs Yes

Color Light green Light grey Grey Light brown
