SPECIFICATIONS TABLE

Our know-how and our support policy also includes taking into account your constraints and tol-
erances, which is why all of our solutions can be made to measure according to your specific plans
and manufacturing processes within a short lead time.

Conductive part Standards GT 1040 GT 1047 GT 1060 GT 1067 GT 2040 GT 2047 GT 2060 GT 2067 Conductive part GT 3140 GT 3147 GT 3160 GT 3167 GT GT GT 5060 GT 5067 BL 10060 BL 10067
5040 5047
Fluoro- Fluorosil- Fluoro- Fluoro- Fluoro- Fluoro- Fluoro- Fluorosili- Fluoro-
Elastomers Silicone Silicone Silicone Silicone Elastomers Silicone Silicone Silicone Silicone Silicone
silicone icone silicone silicone silicone silicone silicone cone silicone
Conductive filler Silver-plated copper Pure Silver Conductive filler Nickel Graphite Silver-plated aluminum Carbon
Volume resistivity Volume resistivity
(Ω-cm) MIL G 83528 < 0.005 < 0.006 (Ω-cm) < 0.10 < 0.0054 6
Hardness (shore A ±7) ASTM D 2240 82 75 Hardness (shore A ±7) 65 65 70
ASTM D 792 Density (g/cm ) 2 1.90 1.22
3
Density (g/cm ) 3.40 3.90
3
Method A
ASTM D 412 Break resistance (Mpa) 1.37 1.89 4.41
Break resistance (Mpa) 2.20 4.61
Method AC
Elongation at break (%) ASTM D 412 250 355 Elongation at break (%) 150 286 150
Method AC
ASTM D 624
Tear strength (kg/cm) Method C 13.70 14 Tear strength (kg/cm) 8.9 8.60 -
Residual deformation
after compression 70 ASTM D 395 17.50 33.12 Residual deformation
hours at 100°C % Method B after compression 70 40 17.30 40
hours at 100°C %
Shielding performance :
20 MHz 130 dB 110 dB Shielding performance :
100 MHz 140 dB 110 dB 20 MHz 100 dB 128 dB 60 dB
500 MHz 120 dB 110 dB 100 MHz 100 dB 137 dB 105 dB
2GHz 120 dB 110 dB 500 MHz 100 dB 133 dB 105 dB
10GHz 120 dB 110 dB 2GHz 100 dB 122 dB 105 dB
10GHz 100 dB 104 dB 105 dB
Working temperature
(°C) -55 to +125 -55 to +160 Working temperature
(°C) -55 to +150 -55 to +160 -55 to +125
Color Beige Light Beige
Color Grey Beige Black
Environmental sealing part Environmental sealing part
Specific mass at 25°C ASTM D 792 1.10 1.43 1.27 1.46 1.10 1.43 1.27 1.46 Specific mass at 25°C 1.10 1.43 1.27 1.46 1.10 1.43 1.27 1.46 1.27 1.46

Hardness (shore A ±5) ASTM D 2240 40 40 60 60 40 40 60 60 Hardness (shore A ±5) 40 40 60 60 40 40 60 60 60 60
Tensile strength Tensile strength
Psi ASTM D 412 1000 1250 950 1200 1000 1250 950 1200 Psi 1000 1250 950 1200 1000 1250 950 1200 950 1200
Mpa 6.80 8.60 6.55 8.30 6.80 8.60 6.55 8.30 Mpa 6.80 8.60 6.55 8.30 6.80 8.60 6.55 8.30 6.55 8.30

Elongation (%) ASTM D 412 500 400 300 300 500 400 300 300 Elongation (%) 500 400 300 300 500 400 300 300 300 300
Residual deformation ASTM D 395 Residual deformation
after compression 22 Method B 30 20 33 25 30 20 33 25 after compression 22 30 20 33 25 30 20 33 25 33 25
hours at 177°C (%) hours at 177°C (%)

Color Orange Blue Blue Light Orange Blue Blue Light blue Color Orange Blue Blue Light Blue Orange Blue Blue Light Blue Blue Light Blue
blue
Available format Molded | Extruded | Customized cutting | Adhered by vulcanization Available format Molded | Extruded | Customized cutting | Adhered by vulcanization
