Environmental sealing materials guide

Fluorosilicone
Silicone
Fluorosilicone products type FVMQ ( ASTM D 1418)
Silicone products type VMQ (ASTM D 1418) Working temperature : -60°C to +230°C
Working temperature : -70°C to +232 °C
These products have a good resistance to solvents, fuels, organic and silicone oils. These
These elastomers are used for the manufacture of molded items, extruded seals, cut flash elastomers are used for the manufacture of molded items, extruded seals, cut flash and seals
seals and seals vulcanized in place. They maintain their mechanical characteristics over a vulcanized in place. They maintain their mechanical characteristics over a broad temperature
broad temperature range. range.

Standard GT 20 GT 30 GT 40 GT 50 GT 60 GT 70 GT 80 Standards GT 37 GT 47 GT 57 GT 67 GT 77
Elastomer Silicone Silicone Silicone Silicone Silicone Silicone Silicone Elastomer Fluorosilicone Fluorosilicone Fluorosilicone Fluorosilicone Fluorosilicone

Hardness (shore A ±5) ASTM D 25 30 40 50 60 70 80 ASTM D
2240
Hardness (shore A ±5)
2240 30 40 50 60 70
Specific mass at 25°C (g/cm3) ASTM D 792 1.10 1.11 1.10 1.19 1.27 1.35 1.43
Specific mass at 25°C (g/cm3) ASTM D 792 1.36 1.43 1.44 1.46 1.48
Tensile strength
Psi ASTM D 412 870 980 1000 980 950 1000 965 Tensile strength 1000 1250 1200 1200 1250
Mpa 6 6.75 6.80 6.75 6.55 6.89 6.65 Psi ASTM D 412 6.90 8.60 8.45 8.30 8.60
Mpa
Elongation (%) ASTM D 412 950 850 500 380 300 180 165
Elongation (%) ASTM D 412 480 400 350 300 300
Residual deformation after
compression 22 hours at ASTM D 395 20 20 30 32 33 34 35 Residual deformation after compression ASTM D 395
177°C (%) Method B 22 hours at 177°C (%) Method B 20 20 25 25 25
Color Red White Orange Red Blue Red Red
Color Blue Blue Blue Blue Blue
Available formats Molded Customized cutting Sheet Extruded Adhered by vulcanization Available formats Molded Customized cutting Sheet Extruded Adhered by vulcanization

Tolerances of our environmental sealing sheets Relationship of compression force to the crushing of molded GT37

Sheet size 300mm x 300mm Sheet size 150mm x 150mm Samples 1 2 3
Thickness (mm) Tolerances Thickness (mm) Tolerances Section diameter (mm) 9.19 9.20 9.24
0.20 ± 0.07 0.20 +0.05 / -0 Nominal thickness (mm) 1.36 1.33 1.38
De 0.30 to 0.40 ± 0.1 De 0.30 to 0.40 ± 0.05 4 1.10 1.10 1.10
0.50 ± 0.15 0.50 ± 0.07 5 1.02 1.05 1.06
0.60 ± 0.15 0.60 ± 0.10 Thickness under pressure (kg) 6 0.95 1.02 1.05
0.70 ± 0.15 0.70 ± 0.10 7 0.90 0.95 1.00
0.80 ± 0.18 0.80 ± 0.15
0.90 ± 0.18 0.90 ± 0.15 Measurements made on molded sheet material. Measurements taken on cut out sections.
From 1.0 to 2.0 ± 0.20 From 1.0 to 2.0 ± 0.15
Greater than 2 ± 13% Greater than 2 ± 13%
The tolerances applicable for control are those shown on this page except when a FAI, a DVI, or a specific control document
are requested to GETELEC.

Contact us for other thickness. Up to 10 mm available
All our sheets are individually checked and given certificates of conformity. Each type of sheet can be made
on request in a fire-resistant version (according to UL 94). We can also provide cut sections to suit the most
appropriate procedure for your requirements : Tool cut, laser cut, water jet cut and flash cut.
